  • UHMWPE Crane Outrigger Pads Stabilizer Jacking Block Custom Cutting and Moulding
  • UHMWPE Crane Outrigger Pads Stabilizer Jacking Block Custom Cutting and Moulding
  • UHMWPE Crane Outrigger Pads Stabilizer Jacking Block Custom Cutting and Moulding
  • UHMWPE Crane Outrigger Pads Stabilizer Jacking Block Custom Cutting and Moulding
UHMWPE Crane Outrigger Pads Stabilizer Jacking Block Custom Cutting and MouldingUHMWPE Crane Outrigger Pads Stabilizer Jacking Block Custom Cutting and MouldingUHMWPE Crane Outrigger Pads Stabilizer Jacking Block Custom Cutting and MouldingUHMWPE Crane Outrigger Pads Stabilizer Jacking Block Custom Cutting and Moulding

UHMWPE Crane Outrigger Pads Stabilizer Jacking Block Custom Cutting and Moulding

  • Product Item : KY-O-001
  • Category: Crane Outrigger pads
  • Density:0.94-0.98g/cm3
  • Raw material:100% Virgin HDPE
  • Product name:Outrigger pads
  • Tensile strength at break:34Mpa
  • INQUIRY   EMAIL


PRODUCT SPECIFICATION

UHMWPE (Ultra-High Molecular Weight Polyethylene) outrigger pads are a specific type of outrigger pad made from a high-performance polymer.

Advantages of UHMWPE outrigger pads:

  • High strength: UHMWPE is extremely durable and can withstand heavy loads without deforming or breaking.
  • Lightweight: Compared to some other materials like steel or concrete, UHMWPE pads are easier to handle and transport.
  • Chemical resistance: Resistant to a wide range of chemicals, making them suitable for use in various environments.
  • Low friction: Reduces the risk of the outriggers sticking or getting damaged when being adjusted.
  • Weather resistance: Can endure harsh weather conditions without deteriorating.

These pads are commonly used in construction, crane operations, and other industries where stability and safety are crucial.

Round Type Specification:

Size(MM) Loading Capacity(Tons) Weight(Kgs)
Dia.650*60 25 19.9
Dia.800*40
20 20
Dia.800*50
25 25
Dia.800*60
30 30.2
Dia.1000*40
35 31.4
Dia.1000*50
40 39.3
Dia.1000*60
45 47
Dia.1000*80
50 62.8
Dia.1000*100
60 75.8
Dia.1200*80
70 90.5
Dia.1200*100
80 113.00
Square type specification

Size(MM) Loading Capacity(Tons) Weight(Kgs)
300*300*25 4 2.3
300*300*30
6 2.7
300*300*40
9 3.6
400*400*25
8 4.0
...... ..... .....
400*400*60
15 9.6
500*500*25
10 6.3
...... ... .....
500*500*60
20 15
600*600*30 13 10.8
..... ..... ....
600*600*60 25 21.6
