Products Description
UHMW polyethylene plate,also known as UHMW-PE (ultra-high molecular weight polyethylene) sheets,are an impact- and corrosion-resistant material
that has a continuous-use temperature range of up to 180°F (82°C). These sheets and bars keep their physical properties at temperatures as low as -22°F (-30°C).
They're durable and do not absorb moisture. These sheets and bars are commonly used for food handling solutions, conveyance mechanisms, and material handling
and packing applications where durability is required.
UHMWPE Plate included Flame Retardant Panels,Glasses-filled UHMWPE Boards,Boron Content UHMWPE Sheet,Unti-UV UHMWPE Sheet and so on.
Advantage
Application
-Highly abrasion-resistance UHMWPE Plate:store/bucket interior lining,port machinery,mining machinery,building machinery,chute,and hopper.
-Pure ultra high UHMWPE Plate:transport machinery,food,packing,paper making,environmental protection,and ceramics.
-Anti-static electric UHMWPE Plate: electroatatic protecting pisitions for mining in the pit,wharf,and foods process.
-Flaming retarding UHMWPE Plate:mining in the pit,mainly used in easily self-inflamation parts,such as coal storehouse.
-Color UHMWPE Plate:packing,decorative material,board fender.
-Double-color UHMWPE Plate:being component to check any wear and tear easily.
-Anti-UV UHMWPE Plate:storehouse or funnel in the open air,board fender.
-Micro-hole UHMWPE Plate:filter-board,anti-skid plate.
-Medical: UHMWPE is the only plastic approved for medical implants.Global Polymer Industries has mesical grade UHMWPE available for molding various orthoprdic joints such as hips,knees,and shoulders.UHMWPE's unique self-lubricating properties make it ideal for many medical applications.
-Owing to its excellent abrasion resistance,impact resistance,self-lubricating,it is suitable for making many types of machinery parts,such as rollers,shaft bushes,nozzle,mixing blade and other products.
Specification
Property
Unit
Value
Density
g/cm3
0.93-0.96
Average molecular weight
g/mol
3million- 10 million
Tensile strength (23°C in air)
MPa
22
Breaking strength
MPa
42
Tensile strain at break
%
600
Charpy impact strength (notched)
mJ/mm2
No break
Ball indentation hardness
N/mm2
42
Shore D hardness
--
65-70
Abrasion
%
70-80, steel = 100
Static Friction Coefficient
--
≤0.16
Kinetic Friction Coefficient
--
≤0.10
Water Absorption
--
NIL
Elongation at break at 23 degress
%
≥300
Temperature resistance
°C
-269 to +85
Melt Temperature
°C
130-140
