High Quality Virgin UHMWPE Plastic Sheets High Impact Virgin UHMWPE BoardHigh Quality Virgin UHMWPE Plastic Sheets High Impact Virgin UHMWPE Board

High Quality Virgin UHMWPE Plastic Sheets High Impact Virgin UHMWPE Board

  • Product Item : KY-U-004
  • Category: UHMWPE Sheet
  • its Density:0.96g/cm3
  • Breaking strength:42Mpa
  • Melt temperature:130°C
  • INQUIRY   EMAIL

Products Description

UHMW polyethylene plate,also known as UHMW-PE (ultra-high molecular weight polyethylene) sheets,are an impact- and corrosion-resistant material

that has a continuous-use temperature range of up to 180°F (82°C). These sheets and bars keep their physical properties at temperatures as low as -22°F (-30°C).

They're durable and do not absorb moisture. These sheets and bars are commonly used for food handling solutions, conveyance mechanisms, and material handling

and packing applications where durability is required.

UHMWPE Plate included Flame Retardant Panels,Glasses-filled UHMWPE Boards,Boron Content UHMWPE Sheet,Unti-UV UHMWPE Sheet and so on.



Advantage


Application

-Highly abrasion-resistance UHMWPE Plate:store/bucket interior lining,port machinery,mining machinery,building machinery,chute,and hopper.

-Pure ultra high  UHMWPE Plate:transport machinery,food,packing,paper making,environmental protection,and ceramics.

-Anti-static electric  UHMWPE Plate: electroatatic protecting pisitions for mining in the pit,wharf,and foods process.

-Flaming retarding  UHMWPE Plate:mining in the pit,mainly used in easily self-inflamation parts,such as coal storehouse.

-Color  UHMWPE Plate:packing,decorative material,board fender.

-Double-color  UHMWPE Plate:being component to check any wear and tear easily.

-Anti-UV  UHMWPE Plate:storehouse or funnel in the open air,board fender.

-Micro-hole  UHMWPE Plate:filter-board,anti-skid plate.

-Medical: UHMWPE is the only plastic approved for medical implants.Global Polymer Industries has mesical grade UHMWPE available for molding various orthoprdic joints such as hips,knees,and shoulders.UHMWPE's unique self-lubricating properties make it ideal for many medical applications.

-Owing to its excellent abrasion resistance,impact resistance,self-lubricating,it is suitable for making many types of machinery parts,such as rollers,shaft bushes,nozzle,mixing blade and other products.

Specification


Property

Unit

Value

Density

g/cm3

0.93-0.96

Average molecular weight

g/mol

3million- 10 million

Tensile strength (23°C in air)

MPa

22

Breaking strength

MPa

42

Tensile strain at break

%

600

Charpy impact strength (notched)

mJ/mm2

No break

Ball indentation hardness

N/mm2

42

Shore D hardness

--

65-70

Abrasion

%

70-80, steel = 100

Static Friction Coefficient

--

≤0.16

Kinetic Friction Coefficient

--

≤0.10

Water Absorption

--

NIL

Elongation at break at 23 degress

%

≥300

Temperature resistance

°C

-269 to +85

Melt Temperature

°C

130-140
